Quad Composite Video Balun

MB-QVB MB-QVB MB-QVBMB-QVB
Model : MB-QVB

*4-CH Composite Video Transmission

*supports NTSC, PAL, SECAM Video

*Composite Video up to 1,000 ft (305m) via Cat5e/6

*Cost-efficient cabling

*Quicker moves, adds and changes
To Purchase Products
Product Information:

Overview

The Quad Video Balun allows up to four composite video signals to be transmitted via unshielded twisted pair (UTP) cable in a point-to-point connection.

Used in pairs, the Quad Video Balun allowing video equipment to be connected via space-efficient and cost-effective Category 5/6 twisted pair cable. The Quad Video Balun supports NTSC, PAL, SECAM video formats for classroom video,

commercial and Home video systems, hospital video training,video conferencing, podium presentation Systems and video kiosks applications and so on.



Applications

Security video, classroom video, commercial and home audio/video systems, hospital video training, video conferencing, podium presentation systems and video kiosks.



Features & Benefits

supports NTSC, PAL, SECAM video

Composite video up to 2,200 ft (670m) via Cat5e/6

Cost-efficient cabling

Quicker moves, adds and changes



Quick Setup Guide:

Plug the RCA connectors of the transmit Balun into the Video outputs of the source component you wish to transmit. Plug the Video  connectors from the receive Balun into your desired input component. Insert the CAT5 cable into both ends of the Baluns. You may use standard EIA 568A/B termination.



Typical Application



Specifications:

Environment

Composite video. NTSC, PAL, SECAM.

Devices

DVD players, cable boxes, video distribution amplifiers, security video cameras, digital video recorders and other composite video equipment.

Transmission



Transparent to the user.

       Bandwidth

0-6 MHz, 3 dB roll off

Maximum Input

     1.1Vp-p

Impedance

       75 ohms

Insertion Loss

Less than 3 dB per pair over the frequency range from DC to 6 MHz

Return Loss

Greater than 15 dB over the frequency range from DC to 6 MHz

Common Mode Rejection Ratio

Greater than 40 dB over the frequency range

Max. Distance Color via

Cat 5E/6 UTP/STP Cable

2,200 ft (670 m)

Pin Configuration (RJ45)

Video 1: Pins 7 (R) & 8 (T) Video 2. Pins 3 (R) & 6 (T)

Video 3: Pins 4 (R) & 5 (T) Video 4: Pins 1 (R) & 2 (T)

Cable: Cat 5E/6 UTP/STP

24 AWG or lower solid copper twisted pair wire

Impedance: 100 ohms at 1 MHz

Maximum capacitance: 20 pf/ft

Attenuation: 6.6 dB/1,000 ft at 1 MHz

Connectors

Four  RCA-F connectors for Composite video

RJ45 for twisted pair

Temperature

Operating: 0° to 55°C

Storage: -20° to 85°C

Humidity: Up to 95% non-condensing

Enclosure

Aluminum alloy

Dimensions(packaging)

155mm*80mm*30mm (including one pair of Balun)

Weight(packaging)

240g



NOTE: Baluns are interchangeable for transmit or receive functions.
